Lubrication Protection for Foundry Applications

Foundries Need High Performance Lubrication

MicroPoly’s solid lubricants are engineered for harsh foundry environments, where heat, metal fines, and contamination quickly break down conventional grease. They use a proprietary oil‑filled polymer that stays in place on bearings, chains, and wheel components, helping prevent lubricant drip, abrasive buildup, and premature wear. By providing long‑term, often “lubed‑for‑life” lubrication in hard‑to‑reach locations, MicroPoly reduces manual relubrication, improves housekeeping around molding lines and conveyors, and helps keep critical foundry equipment running reliably.

Foundry Lubrication: Case Studies and Results

  • Bearing Type: SealMaster SFT 35E – 2 bolt flange, 2-7/16″ bore
  • Conditions: Buried in sulfur-contaminated sand. Bearing was contained with an end cap. Temperature 110°F. Bearing life 6 months.
  • Results: Bearing life is now 12 months and the greasing schedule has been reduced. End cap was eliminated.

  • Bearing Type: Roller and ball bearings
  • Conditions: Higher than room temperature and sand contamination caused premature and inconsistent bearing life. The bearings could not be re-lubricated, complicating the bearing life problem further, causing excessive downtime and high maintenance costs.
  • Results: Bearing life was increased to 6-7 years, substantially improving uptime and reducing maintenance costs.

  • Bearing Type: Ball bearings, 1-1/2″ and 2″ bore
  • Conditions: Higher than room temperature and sand contamination caused premature and inconsistent bearing life. The bearings could not be re-lubricated, complicating the bearing life problem further, causing excessive downtime and high maintenance costs.
  • Results: Bearing life was increased 3 to 4 fold. Based on an internal cost study, MicroPoly became the standard for these bearings.

  • Bearing Type: Single row ball bearing, 6212
  • Conditions: Sand contamination. Speed 150 RPM. Bearing life 1 to 4 weeks.
  • Results: Bearing life has been extended to 12 months.

  • Bearing Type: 6″ wheels
  • Conditions: Conveyor carries parts through system with the wheels exposed to shot blast process. This causes the wheel cover to come off which allows shot material to enter and destroy the bearings. Manual lubrication was required which caused down time and additional labor costs. Liquid lubricant has caused fires periodically.
  • Results: MicroPoly is keeping the shot material out of the bearing, even when the wheel cover comes off. The life of the wheels has increased.

  • Bearing Type: Linkbelt F3 U231N, 2-15/16″ flange
  • Conditions: Sand and steel shot fines contamination. Speed 60 RPM. Bearing life 2 months.
  • Results: Bearing life has been extended to 11 months.

Need Help Choosing a Lubricant?

Please reach out to us or your local representative, and we will help in any way we can.
