Lubrication Protection for Chain Applications

Chains Need High Performance Lubrication

MicroPoly’s solid lubrication solutions for chains replace traditional drip or spray oils with a proprietary oil‑filled polymer that stays in place on the chain and sprocket surfaces, delivering consistent lubrication without dripping or fling‑off. This reduces contamination, housekeeping issues, and frequent relubrication, helping chains run cleaner and longer with less maintenance in demanding industrial and automotive environments.

Chain Lubrication: Case Studies and Results

MicroPoly Type: MicroPoly Sprocket for #60 chain
Conditions: Automation was designed without chain lubrication, causing problems with chain wear and unacceptable chain life.
Results: MicroPoly sprockets operated successfully for 7 years with no noticeable wear on either the chain or the sprockets.

MicroPoly Type: 1″ x 2″ x 18″ conveyor chain lubrication block is used to lubricate #80 chain, 50 feet long with a 24 foot center distance between 8″ sprockets.
Conditions: Chain was lubricated every month with molybdenum disulphide grease, which left marks on the wood boards as they moved on the line. The excess grease dripped, creating safety hazards and housekeeping problems and contaminating the wood. The chain became noisy in about 6 weeks if not lubricated. Chain speed was 1 revolution every 2 minutes.
Results: The MicroPoly lubrication blocks have been in use for 6 years without replacement. The blocks are mounted between two plates with spring pressure applied. MicroPoly has eliminated the problems they were having with contamination, housekeeping, and safety.

MicroPoly Type: 1” x 2″ x 12″ chain lube block
Conditions: Frictional heat on expensive profiled UHMW chain guide caused softening of guide and replacement of 40 blocks, 2 or 3 times per year.
Results: Customer cut MicroPoly blocks into 6” lengths and machined sides down to provide two raised shoulders. MicroPoly has doubled the life of the UHMW. Change out on the guides had cost customer $500 per block. 40 blocks x 2 of MicroPoly changes per year saved $20,000.

MicroPoly Type: 1″ x 2″ x 12″ conveyor chain lubrication block
Conditions: Either no lubrication was used, with a short chain life experienced, or manual greasing was required. The alternative was an expensive automatic lubrication system that tended to drip, creating housekeeping and safety problems.
Results: Housekeeping and safety problems were eliminated with no manual greasing requirements.

MicroPoly Type: 1″ x 2″ x 20′ conveyor chain lubrication block
Conditions: UHMW guide material supporting the chain wore out prematurely. This resulted in inconsistent parts feeding problems. The chain would disengage from sprockets when worn down, leading to frequent guide replacement.
Results: With MicroPoly, inconsistent parts feeding problems and frequent guide replacement were eliminated. After 3 years of use, the blocks are still functioning.

MicroPoly Type: 1″ x 2″ x 12′ chain lube block
Conditions:Some radiant heat, less than 200 degrees. Previous chain guide material did not hold up and had to be replaced 3 or 4 times per year.
Results: MicroPoly chain lube blocks, placed at interval spacing, reduced replacement frequency of chain guide to once per year. This resulted in saving significant material replacement and labor costs.

MicroPoly Type: MicroPoly Sprocket for double #40 chain
Conditions: Conveyor chain was periodically manually lubricated with an oil sprayer. This caused the oil to drip, thus creating the need to contain the excess oil in pans. Because of the severe safety hazard, the steel pans had to be cleaned out before the equipment, and the chain could be serviced.
Results: MicroPoly sprockets have eliminated the safety hazard and increased the chain life.

MicroPoly Type: 1″ x 2″ x 8″ conveyor chain lubrication block
Conditions: Water and dirt get into pins. Chain life is very short. Application is indoors with no heat.
Results: Results are very good. All conveyor chains are now lubricated in this manner.
